Agricultural oil pump with high head up to 10m
Standard Model: OP01B-13001512
Voltage: 12V
Current: 16.0A
Open Flow: 13GPM/50LPM
Head (Max): 10 meters
Ports: 3/4" BSP
INDFLO diesel refuelling pump is a self-priming diesel pump for reliable and efficient performance. Powered by 12/24V mains supply, its maximum transfer is up to 50 liters per minute at 3 meters head. It offers an easy and compact installation on earth moving machinery like excavators, cranes, road rollers, generators, etc. Suitable for diesel, kerosene, paraffin, hydraulic oils, oils up to 150 centi Stokes (750 Saybolt universal) viscosity.
| Model | Volts | Open Flow | Current | Fuse | Suction | Head | Ports |
| OP01B-15001012 | 12V | 13GPM/50LPM | 16A | 25A | 3m | 10m | 3/4" BSP |
| OP01B-15001024 | 24V | 8A | 15A | 3/4" BSP | |||
| OP01N-15001012 | 12V | 16A | 25A | 3/4" NPT | |||
| OP01N-15001024 | 24V | 8A | 15A | 3/4" NPT |
